6" Submersible Pump Sets
Special features
- All pumps are dynamically designed for ensured maximum efficiency.
- Wide range of pump sets suitable for various application.
- Motor are easy revindable.
- High performance at low voltage.
- Energy efficient pump rated by various government departments.
- Available in single phase also.(for specific models only)
Material Strength
Stampings | CRNO. With M-45 grade | |
Bowl | FG210 | |
Impeller | AISI410 | |
Thrust bearing | Carbon/ AISI 420 | |
Shaft | S.S 410 | |
Stator body | AISI202(2%Ni) | |
End Ring | Stainless steel |
Operating Parameters
HP / KW Rating | 3.0 to 30 HP / 2.3 to 22.3 KW | |
Discharge Range | Upto 1600 lpm | |
Head Range | Upto 388 Mtrs. |
