Special features

• All pumps are dynamically designed for ensured maximum efficiency.
• Wide range of pump sets suitable for various application.
• Motor are easy re-vendible .
• High performance at low voltage.
• Energy efficient pump rated by various government departments.
• Available in single phase also.(for specific models only)

Material Strength

Stampings		CRNO. With M-45 grade
Bowl		FG210
Impeller		AISI410
Thrust bearing		Carbon/ AISI 420
Shaft		S.S 410
Stator body		AISI202(2%Ni)
End Ring		Stainless steel

Operating Parameters

HP / KW Rating		5.0 to 30 HP / 3.8 to 22.3 KW
Discharge Range		Upto 2100 lpm
Head Range		Upto 178 Mtrs.
